Float & Board Level Indicators for Pressurized Tanks are designed for an accurate, reliable & trouble free float operated technique used in large tanks where there is blanketing system or, there are fumes / vapours in the tank by which tank gets pressurized.
Range : 2 meters up to 6 meters
Gauge Board : Follower Magnet type Indicator in provided in a transparent vertical tube.
Float wire : 2mm dia.x SS 304 /SS 316 (multistrand) / 6mm dia. x PP (multistrand)
Guide Wires : 2mm dia.x SS 304 /SS 316 (multistrand) / 6mm dia. x PP (multistrand)
Float : SS 316, 300 mm dia X 75 mm height.
Sheave assembly : Aluminum Housing, 2 nos. SS pulleys with Teflon bushes
Indicator assembly : MS Painted
Brackets for scale and indicator: MS Powder coated
Nuts & Bolts : Zink plated MS
Optional : Externally settable Switches for Control system or, feed backs.
